Download Name | File Size |
inst-t56.pdf | 383.93KB |
Certification | 6.1 SFI |
Clutch Diameter | 11 inches |
Clutch Operation | Hydraulic |
Color | Black |
Emission Code | 5 |
Engine | GM Small Block Gen III/IV (LS Based), Chevy LT1 |
Engine Make | Chevrolet |
Engine Plate | RM-6023-C |
Flywheel | 153/168 Tooth |
Height | 4.950 inch |
Height (in) | 4.95 |
Included Hardware | Full engine plate |
Make | Chevrolet |
Material | Steel |
Part Type | Transmission Bell Housing |
Patented | yes |
Product Type | Bellhousing |
SFI | 6.1 |
SFI Approved | Yes |
SFI Certification | 6.1 |
Trans Bore | N/A |
Trans. Bore Diameter | N/A |
Transmission | T56 GM |
Transmission Type | Manual |
Weight | 22# |
Weight (lb) | 22 |
